Flat Coupling Press Machines

The coupling press Art. AP ES automatically manages the coupling and pressing of IG units efficiently and with absolute precision. Processing rigid box and or flexible spacer frame units, with either double or triple glass pieces is seamless (one or two chambers up to 65 mm of thickness). The platform can be specified with an associated gas filling system (argon). The inbound glass piece is automatically scanned for height, width and thickness as are the subsequent glass pieces with the addition of the spacer width. The onboard system then calculates the amount of gas required to fill the associated cavity.

The tandem gas filling coupling press Art. AP NL has been designed to manage big size of glass sheets. Equipped with an exclusive retractable suction cups system also on the rear surface, Art. AP NL can straight any curvatures (even with laminated glass) and ensure an uniform gas filling. The coupling press can process insulating glass panes with up to 3 chambers. It is also equipped with a double circuit for the emission of the gas: it can therefore use two different products for filling the chamber (argon/krypton).
